2. Cloud Resume Challenge: GitHub and GitHub Actions

To get started within this module, you will be creating a GitHub repo from the template repo. Then you will prepare your Terraform Cloud environment with some configurations in preparation for creating your AWS infrastructure.

Let's get started!

Cloning Template Repository

Login to GitHub
Go to my template > Select Use this template > Select Create a new repository

Input a Repo name and Description
Select Create repository

Cloning your repo

In your IDE terminal, clone your repository.

git clone https://github.com/YOUR_REPOSITORY.git PATH_TO_SAVE_LOCATION

Open the folder from your cloned repo

Create a New Branch in your repo

In GitHub, select Issues > New Issue
Enter a title for your issue, e.g. Modify GitHub Actions
Enter a description if you'd like
Select Submit new issue

On the right hand pane, under Development, select Create a branch

Leave the defaults and select Create branch

Open your IDE Terminal.
Input the following:

git fetch origin

git checkout YOUR_BRANCH_NAME

Configure Terraform Cloud

Login to Terraform
Select Projects & workspaces > Select New > Project

Input your Project Name
Select New > Workspace

Select API-Driven Workflow
Input your Workspace Name
Select the Project you created from the drop-down

Select Create

You will be taken to the Overview page for this workspace. You will see some Example code on this page with your organization and workspace name.

Take note of these.

On the left pane, Select Settings

Under the General section, scroll down and find the Terraform Working Directory

./infra

Save your change at the bottom

Creating Variables

Go back to the Overview page, select Variables

Create the following variables:
- AWS_ACCESS_KEY_ID - Select the Sensitive dialog box
  - Select Add variable
- AWS_SECRET_ACCESS_KEY - Select the Sensitive dialog box
  - Select Add variable

Creating Terraform API Token

At the top of the left pane, select your profile drop-down > Select Account Settings

Under Account Settings, Select Tokens
Select Create an API Token

Enter a name/description of the token and set an expiration date for it

Select Generate Token

Take note of the output from the token. You will need this for your GitHub Secrets

Add GitHub Secrets

Go back to GitHub
Select your repo for this project
Select Settings on the top right

On the left pane under Security, Select Secrets and variables > Actions

Select New repository secret
Create the following Secrets:
- AWS_ACCESS_KEY_ID - same information as the Terraform Cloud Variable.
- AWS_SECRET_ACCESS_KEY - same information as the Terraform Cloud Variable.
- TF_API_TOKEN - output from Terraform Cloud API Token.

NOTE: AWS_ACCESS_KEY_ID and AWS_SECRET_ACCESS_KEY will be utilized later for CloudFront invalidations.

Update .yml files

Open your IDE
Update your terraform-plan.yml and terraform-apply_cloudfront-invalidation.yml files to reflect your Organization and Workspace.

Save your files

Update ./infra/providers.tf

Update your providers.tf to include your organization, workspace and AWS region.

Save the file

Pushing to GitHub

Ensure your files are saved.
In your IDE Terminal, type the following:

git add .

Add all files that were changed.


git commit -m "updated .yml files with terraform organization and workspace."

Commit the changes with a comment.

git push

Push to GitHub.

Create Pull Request

Go to GitHub
You should see the push on your repository

Select Compare & pull request
Validate the changes that were made to be pushed to main
Select Create pull request
Select Merge pull request

Confirm merge
Delete Branch
In your IDE Terminal, input the following:

git checkout main

This will checkout main and swap out of your branch

git pull

This will pull the configuration from GitHub so that main is in sync

In the next module, you modify some of your terraform files to create an Amazon S3 Bucket. You'll also make modifications again to your GitHub workflow so that your resources will be created automatically.
